Application Scope
The
uv led chip produced by Learnew Optoelectronics Technology has a wide range of applications.Learnew Optoelectronics Technology insists on providing customers with comprehensive solutions based on their actual needs, so as to help them achieve long-term success.
Company Advantages1. When it comes to comparing with other products, Learnew uv chip led is of greater appearance.
2. It has exceeded the national superior product inspection standards.
3. The product has been tested for a long time and thus has a stable performance.
4. Shenzhen Learnew Optoelectronics Technology Co., Ltd. will continue to provide the best customer service.
5. Shenzhen Learnew Optoelectronics Technology Co., Ltd. pays high attention to quality problem to seek for long-term development.
UV LED Array series
UV LED R&D,Manufacture is one of important business structure in Learnew.Since 2013,Learnew first time present “Inorganic encapsulation” in high power UVA package,Core technical is we manage the most efficiency output and thermal resistance design.Even in 300-600W,Learnew UV series give best performance in lifetime and continual stable output.
Learnew UV(UVA & UVC) 1-600W series for different UV application,such as offset printer,exposure application,large-scale inkjet printer,3D printer,Printing & Curing application,Sterillization etc.Learnew standard design UVA(360-410nm) & UVC(260-280nm) for your pleasure need.
Product feature
◪ Inorganic encapsulation
◪ Lowest thermal resistance design
◪ High efficiency output
◪ High optical intensity design
◪ Narrow & single peak wavelength design
◪ Pure color output
| UV-A | LN-CVB75UV-P84 |
| POWER | 135-188W |
| Dominant Wavelength | 365nm | 385nm | 395nm |
| Optical Power | 65000-85000mW | 82000-96000mW | 86000-100000mW |
| IF | 6000-8400mA
(Test=6000mA) |
| VF | 23-26V |
| WHOLE SIZE | 75*30MM |
| Lighting Area | 40*20MM |
| VIEW ANGLE | 30° |
| LENS | QUARTZ GLASS LENS |
| SUBSTRATE | ALN Coppering |
| CHIPS | VERTICAL EPISTAR
(LG or HPO) |
Note:
A.PRICE IS WITHOUT VAT, AND KPCS=1000PCS.
B.EX-WORK QUOTE BASE,SHIPPING COST IS NOT INCLUDED.
C.WARRANTY IS 2 YRS.
D.PREPAID IS REQUIRED ONCE ORDER CONFIRMED,TT BALANCE ONCE READY TO SHIPPING.
E.PRODUCTION CYCLE IS 7-10 WORK DAYS.
F.OEM & ODM IS ACCEPTABLE.
Company Features1. Shenzhen Learnew Optoelectronics Technology Co., Ltd.'s products sell well on international market.
2. Up until now, Shenzhen Learnew Optoelectronics Technology Co., Ltd. has possessed an outstanding systematic ability to develop new uv cob led products.
3. Such business principles and strategic guidelines as uv chip led have been formed through the course of Shenzhen Learnew Optoelectronics Technology Co., Ltd.'s development. Inquiry! Efforts will be made to build service-oriented and innovative companies by Shenzhen Learnew Optoelectronics Technology Co., Ltd. to provide a top-quality led cob 200w . Inquiry!
