Product parameters
FLIP CHIP | 4046 SERIES | ||
POWER | 40W-60W | 80W-120W | 150W-200W |
CCT | 2700-6500K | 2700-6500K | 2700-6500K |
LM/W | 120-140 | 120-140 | 110-130 |
IF | 1350-2700mA | 2500-4500mA | 2500-4500mA |
VF | 30-33V | 30-33V | 42-48V |
WHOLE SIZE | 40X46MM | 40X46MM | 40X46MM |
EMIT SIZE | 25MM | 25MM | 25MM |
VIEW ANGLE | 120° | ||
CRI | 70/80 | ||
SUBSTRATE | Super-Aluminum |
Note:
A.PRICE IS WITHOUT VAT.
B.EX-WORK QUOTE BASE,SHIPPING COST IS NOT INCLUDED.
C.WARRANTY IS 3 YRS.
D.PREPAID IS REQUIRED ONCE ORDER CONFIRMED,TT BALANCE ONCE READY TO SHIPPING.
E.PRODUCTION CYCLE IS 7-10 WORK DAYS.
F.OEM & ODM IS ACCEPTABLE.
Product Details
Product application
The modules light output are intense enough to cause injury to human eyes if viewed directly. Precautions must be taken to avoid looking directly at the modules with unprotected eyes.
2.
The modules are sensitive to electrostatic discharge. Appropriate ESD protection measures must be taken when working with the modules. Non-compliance with ESD protection measures may lead to damage or destruction of the product.
3.
Chemical solvents or cleaning agents must not be used to clean the modules. Mechanical stress on the Emitters must be avoided. It is best to use a soft brush, damp cloth or low-pressure compressed air.
4.
The products should be stored away from direct light in dry location.
5.
The appearance, specifications and flux bin of the product may be modified for improvement without notice. Please refer to the below website for the latest datasheets.
