Product Comparison
Learnew Optoelectronics Technology's
uv led chip is commonly praised in the market due to good materials, fine workmanship, reliable quality, and favorable price. uv led chip has the following advantages over other products in the same category.
Company Advantages1. With carefully selected materials, our led cob 200w have received much fame until now.
2. The high quality and good usability give the product an edge to compete in the global market.
3. For years, HENZHEN LEARNEW OPTOELECTRONICS TECHNOLOGY CO LIMITED. has went on the led cob 200w market in an invincible position.
4. Our mission in HENZHEN LEARNEW OPTOELECTRONICS TECHNOLOGY CO LIMITED. is to satisfy our customers not only in quality but also in service.
UV LED Array series
UV LED R&D,Manufacture is one of important business structure in Learnew.Since 2013,Learnew first time present “Inorganic encapsulation” in high power UVA package,Core technical is we manage the most efficiency output and thermal resistance design.Even in 300-600W,Learnew UV series give best performance in lifetime and continual stable output.
Learnew UV(UVA & UVC) 1-600W series for different UV application,such as offset printer,exposure application,large-scale inkjet printer,3D printer,Printing & Curing application,Sterillization etc.Learnew standard design UVA(360-410nm) & UVC(260-280nm) for your pleasure need.
Product feature
◪ Inorganic encapsulation
◪ Lowest thermal resistance design
◪ High efficiency output
◪ High optical intensity design
◪ Narrow & single peak wavelength design
◪ Pure color output
| UV-A | LN-CVB75UV-P84 |
| POWER | 135-188W |
| Dominant Wavelength | 365nm | 385nm | 395nm |
| Optical Power | 65000-85000mW | 82000-96000mW | 86000-100000mW |
| IF | 6000-8400mA
(Test=6000mA) |
| VF | 23-26V |
| WHOLE SIZE | 75*30MM |
| Lighting Area | 40*20MM |
| VIEW ANGLE | 30° |
| LENS | QUARTZ GLASS LENS |
| SUBSTRATE | ALN Coppering |
| CHIPS | VERTICAL EPISTAR
(LG or HPO) |
Note:
A.PRICE IS WITHOUT VAT, AND KPCS=1000PCS.
B.EX-WORK QUOTE BASE,SHIPPING COST IS NOT INCLUDED.
C.WARRANTY IS 2 YRS.
D.PREPAID IS REQUIRED ONCE ORDER CONFIRMED,TT BALANCE ONCE READY TO SHIPPING.
E.PRODUCTION CYCLE IS 7-10 WORK DAYS.
F.OEM & ODM IS ACCEPTABLE.
Company Features1. Being a leading brand in the production of led cob 200w has always been the positioning of the Learnew brand.
2. HENZHEN LEARNEW OPTOELECTRONICS TECHNOLOGY CO LIMITED. has strong technical force and exquisite workmanship.
3. Learnew is confident to provide you the most comprehensive services and products of high quality. Please contact us! Learnew has been providing high quality service for customers. Please contact us!
