Company Advantages1. The whole production of Learnew uv cob led is supported by the technicians with extensive industry expertise and the leading production technology. The product has a tough and rigid surface to protect it from pressure
2. Its heat sink is conducive to its durability Customized
uv led chip is available based on your detailed requirements.
3. The product is strictly tested by the quality team on a series of parameters ensuring its quality. It needs no welding which greatly reduces the production cost
UV LED Array series
UV LED R&D,Manufacture is one of important business structure in Learnew.Since 2013,Learnew first time present “Inorganic encapsulation” in high power UVA package,Core technical is we manage the most efficiency output and thermal resistance design.Even in 300-600W,Learnew UV series give best performance in lifetime and continual stable output.
Learnew UV(UVA & UVC) 1-600W series for different UV application,such as offset printer,exposure application,large-scale inkjet printer,3D printer,Printing & Curing application,Sterillization etc.Learnew standard design UVA(360-410nm) & UVC(260-280nm) for your pleasure need.
Product feature
◪ Inorganic encapsulation
◪ Lowest thermal resistance design
◪ High efficiency output
◪ High optical intensity design
◪ Narrow & single peak wavelength design
◪ Pure color output
UV-A | LN-CVB75UV-P84 |
POWER | 135-188W |
Dominant Wavelength | 365nm | 385nm | 395nm |
Optical Power | 65000-85000mW | 82000-96000mW | 86000-100000mW |
IF | 6000-8400mA (Test=6000mA) |
VF | 23-26V |
WHOLE SIZE | 75*30MM |
Lighting Area | 40*20MM |
VIEW ANGLE | 30° |
LENS | QUARTZ GLASS LENS |
SUBSTRATE | ALN Coppering |
CHIPS | VERTICAL EPISTAR
(LG or HPO) |
Note:
A.PRICE IS WITHOUT VAT, AND KPCS=1000PCS.
B.EX-WORK QUOTE BASE,SHIPPING COST IS NOT INCLUDED.
C.WARRANTY IS 2 YRS.
D.PREPAID IS REQUIRED ONCE ORDER CONFIRMED,TT BALANCE ONCE READY TO SHIPPING.
E.PRODUCTION CYCLE IS 7-10 WORK DAYS.
F.OEM & ODM IS ACCEPTABLE.
Company Features1. Since Shenzhen Learnew Optoelectronics Technology Co., Ltd. was officially put into production, it has been developing steadily in the industry of uv cob led. By training more professional and technical personnel, Learnew is more confident to produce the highest quality products uv led chip.
2. Shenzhen Learnew Optoelectronics Technology Co., Ltd. has advanced manufacturing technology and processes.
3. Shenzhen Learnew Optoelectronics Technology Co., Ltd. makes extensive use of its professional engineers and technicians. In every production process of smd chip led lamp, we always maintain a professional attitude. Ask online!
