Company Advantages1. The appealing design of Learnew
led chip model comes from a team of talented professionals. Its transmittance of light is highly recognized
2. The professional service of Learnew has left impression on many customers. It's free of lens or other components and greatly reduce optical loss
3. The product is no doubt qualified in quality as it has already passed multiple quality tests. Its serialization of the original chip can be customized
UV LED Array series
UV LED R&D,Manufacture is one of important business structure in Learnew.Since 2013,Learnew first time present “Inorganic encapsulation” in high power UVA package,Core technical is we manage the most efficiency output and thermal resistance design.Even in 300-600W,Learnew UV series give best performance in lifetime and continual stable output.
Learnew UV(UVA & UVC) 1-600W series for different UV application,such as offset printer,exposure application,large-scale inkjet printer,3D printer,Printing & Curing application,Sterillization etc.Learnew standard design UVA(360-410nm) & UVC(260-280nm) for your pleasure need.
Product feature
◪ Inorganic encapsulation
◪ Lowest thermal resistance design
◪ High efficiency output
◪ High optical intensity design
◪ Narrow & single peak wavelength design
◪ Pure color output
| UV-A | LN-CVB75UV-P84 |
| POWER | 135-188W |
| Dominant Wavelength | 365nm | 385nm | 395nm |
| Optical Power | 65000-85000mW | 82000-96000mW | 86000-100000mW |
| IF | 6000-8400mA
(Test=6000mA) |
| VF | 23-26V |
| WHOLE SIZE | 75*30MM |
| Lighting Area | 40*20MM |
| VIEW ANGLE | 30° |
| LENS | QUARTZ GLASS LENS |
| SUBSTRATE | ALN Coppering |
| CHIPS | VERTICAL EPISTAR
(LG or HPO) |
Note:
A.PRICE IS WITHOUT VAT, AND KPCS=1000PCS.
B.EX-WORK QUOTE BASE,SHIPPING COST IS NOT INCLUDED.
C.WARRANTY IS 2 YRS.
D.PREPAID IS REQUIRED ONCE ORDER CONFIRMED,TT BALANCE ONCE READY TO SHIPPING.
E.PRODUCTION CYCLE IS 7-10 WORK DAYS.
F.OEM & ODM IS ACCEPTABLE.
Company Features1. Shenzhen Learnew Optoelectronics Technology Co., Ltd. is rich in its product line and is popular among many different countries.
2. All our rgb uv led are produced to comply with the latest fashion trend.
3. Learnew Optoelectronics always listens earnestly and objectively to the needs of the customer. Get price!
