Application Scope
The ac cob led of Learnew Optoelectronics Technology is applicable in the following scenes.Learnew Optoelectronics Technology insists on providing customers with comprehensive solutions based on their actual needs, so as to help them achieve long-term success.
Enterprise Strength
-
Learnew Optoelectronics Technology gives priority to customers and runs the business in good faith. We are devoted to providing quality services.
Company Advantages1. The structure of rgb uv led is flexible and reasonable.
2. uv chip led makes rgb uv led to be operated well.
3. rgb uv led has been recognized as uv chip led .
4. This product can effectively make a room more useful and easier to maintain. With this product, people are living a more comfortable life.
UV LED Array series
UV LED R&D,Manufacture is one of important business structure in Learnew.Since 2013,Learnew first time present “Inorganic encapsulation” in high power UVA package,Core technical is we manage the most efficiency output and thermal resistance design.Even in 300-600W,Learnew UV series give best performance in lifetime and continual stable output.
Learnew UV(UVA & UVC) 1-600W series for different UV application,such as offset printer,exposure application,large-scale inkjet printer,3D printer,Printing & Curing application,Sterillization etc.Learnew standard design UVA(360-410nm) & UVC(260-280nm) for your pleasure need.
Product feature
◪ Inorganic encapsulation
◪ Lowest thermal resistance design
◪ High efficiency output
◪ High optical intensity design
◪ Narrow & single peak wavelength design
◪ Pure color output
| UV-A | LN-CVS35UV-P120 |
| POWER | 192-300W |
| Dominant Wavelength | 365nm | 385nm | 395nm |
| Optical Power | 95000-110000mW | 120000-140000mW | 125000-150000mW |
| IF | 6000-8400mA
(Test=8400mA) |
| VF | 34-38V |
| WHOLE SIZE | 35*35MM |
| Lighting Area | 22*35MM |
| VIEW ANGLE | 120° |
| LENS | QUARTZ GLASS LENS |
| SUBSTRATE | ALN Coppering |
| CHIPS | VERTICAL EPISTAR
(LG or HPO) |
Note:
A.PRICE IS WITHOUT VAT, AND KPCS=1000PCS.
B.EX-WORK QUOTE BASE,SHIPPING COST IS NOT INCLUDED.
C.WARRANTY IS 2 YRS.
D.PREPAID IS REQUIRED ONCE ORDER CONFIRMED,TT BALANCE ONCE READY TO SHIPPING.
E.PRODUCTION CYCLE IS 7-10 WORK DAYS.
F.OEM & ODM IS ACCEPTABLE.
Company Features1. SHENZHEN LEARNEW OPTOELECTRONICS TECHNOLOGY CO LIMITED. is an international company focusing on serving the uv chip led market.
2. SHENZHEN LEARNEW OPTOELECTRONICS TECHNOLOGY CO LIMITED. closely relies on scientific and technological progress, introduces advanced equipment from overseas.
3. We have a clear business strategy: green production. This means we will seek to minimize the negative impact of the production process on the environment at every stage, including minimizing emissions, controlling wastes, and minimizing the life-cycle cost of products. Sustainability is a core element of our company. We have made and strictly follow the product criteria that take into account sustainability aspects across the entire life cycle for the evaluation of products. All of our business activities and production practices comply with environmental regulations. We will spare no effort to reduce our negative environmental influence during our production activities.
