new arrival uv cob led cheapest factory price high quality
1. Learnewuv cob led is designed by the elite design team based on user demand.
2. Skillful employees and a range of equipment guarantee the product quality.
3. uv cob led is developed under new technology with advantages of led chip model and low costs.
4. Its high color rendition performance offers users with homogeneous illumination distribution and a shadow-free lighting environment, which provides great convenience for users.
Our products
Learnew UV(UVA & UVC) 1-600W series for different UV application,such as offset printer,exposure application,large-scale inkjet printer,3D printer,Printing & Curing application,Sterillization etc.Learnew standard design UVA(360-410nm) & UVC(260-280nm) for your pleasure need.
◪ Inorganic encapsulation
◪ Lowest thermal resistance design
◪ High efficiency output
◪ High optical intensity design
◪ Narrow & single peak wavelength design
◪ Pure color output
Product parameters
| UV-A | LN-SMD6868UV-P4 | ||
| POWER | 5-10W | ||
| Dominant Wavelength | 365nm | 385nm | 395nm |
| Optical Power | 3200-4000mW | 4000-4500mW | 4100-5000mW |
| IF | 500-700mA (Test=700mA) | ||
| VF | 12-15V | ||
| WHOLE SIZE | 6.8*6.8MM | ||
| Lighting Area | R5.0MM | ||
| VIEW ANGLE | 60° | ||
| LENS | QUARTZ GLASS LENS | ||
| SUBSTRATE | ALN Coppering | ||
| CHIPS | VERTICAL EPISTAR (LG or HPO) | ||
Note:
A.PRICE IS WITHOUT VAT, AND KPCS=1000PCS.
B.EX-WORK QUOTE BASE,SHIPPING COST IS NOT INCLUDED.
C.WARRANTY IS 2 YRS.
D.PREPAID IS REQUIRED ONCE ORDER CONFIRMED,TT BALANCE ONCE READY TO SHIPPING.
E.PRODUCTION CYCLE IS 7-10 WORK DAYS.
F.OEM & ODM IS ACCEPTABLE.
Product Details
Product application
Company Features
1. Learnew brand has been ranking top in the market of uv cob led .
2. Learnew has a complete assortment of production facilities and advanced technology.
3. Pursuit of excellence both in service and led cob 200w quality will be Learnew's unceasing goal. Inquiry! HENZHEN LEARNEW OPTOELECTRONICS TECHNOLOGY CO LIMITED. aims to become a benchmark of innovation in rgb uv led industry. Inquiry! With the support of professional team, Learnew has won much recognition. Inquiry!
