    UV LED Array series
    UV LED R&D,Manufacture is one of important business structure in Learnew.Since 2013,Learnew first time present “Inorganic encapsulation” in high power UVA package,Core technical is we manage the most efficiency output and thermal resistance design.Even in 300-600W,Learnew UV series give best performance in lifetime and continual stable output.
    Learnew UV(UVA & UVC) 1-600W series for different UV application,such as offset printer,exposure application,large-scale inkjet printer,3D printer,Printing & Curing application,Sterillization etc.Learnew standard design UVA(360-410nm) & UVC(260-280nm) for your pleasure need.
    Product feature
    • ◪   Inorganic encapsulation

    • ◪   Lowest thermal resistance design

    • ◪   High efficiency output

    • ◪   High optical intensity design

    • ◪   Narrow & single peak wavelength design

    • ◪   Pure color output



    PRODUCT PARAMETERS


    Support Customization 365-405nm 3W 10W 50W 100W 200W 300W 400W UV Chip SMD UVA LED Apply to led uv floor curing machine 8
    UV-ALN-CVS35UV-P120
    POWER300W
    Dominant Wavelength365nm385nm395nm
    Optical Power95000-110000mW120000-140000mW125000-150000mW
    IF6000-8400mA
    (Test=8400mA)
    VF34-38V
    WHOLE SIZE35*35MM
    Lighting Area22*35MM
    VIEW ANGLE120°
    LENSQUARTZ GLASS LENS
    SUBSTRATEALN Coppering
    CHIPSVERTICAL EPISTAR
    (LG or HPO)


    Note:
          A.PRICE IS WITHOUT VAT, AND KPCS=1000PCS.
          B.EX-WORK QUOTE BASE,SHIPPING COST IS NOT INCLUDED.
          C.WARRANTY IS 2 YRS.
          D.PREPAID IS REQUIRED ONCE ORDER CONFIRMED,TT BALANCE ONCE READY TO SHIPPING.
          E.PRODUCTION CYCLE IS 7-10 WORK DAYS.
          F.OEM & ODM IS ACCEPTABLE.
