Company Advantages1. The mature production process of Learnew cob module led makes it more valuable. It's mainly used in flashlights, downlights street lights, and high bay lights
2. This product is very profitable and brings benefits to customers. Adopted the heat sink technology, it has a high lumen maintenance rate
3. The cleaning and maintenance of
uv led chip should be cob module led . It's free of lens or other components and greatly reduce optical loss
4. Our uv led chip is characterized by high performance and stable quality. The encapsulation way of the product can resist ultraviolet
5. Learnew integrates cob module led and led chip model into together to ensure the safety of uv led chip . Its narrow and single peak wavelength provides the most efficiency spectrum
UV LED Array series
UV LED R&D,Manufacture is one of important business structure in Learnew.Since 2013,Learnew first time present “Inorganic encapsulation” in high power UVA package,Core technical is we manage the most efficiency output and thermal resistance design.Even in 300-600W,Learnew UV series give best performance in lifetime and continual stable output.
Learnew UV(UVA & UVC) 1-600W series for different UV application,such as offset printer,exposure application,large-scale inkjet printer,3D printer,Printing & Curing application,Sterillization etc.Learnew standard design UVA(360-410nm) & UVC(260-280nm) for your pleasure need.
Product feature
◪ Inorganic encapsulation
◪ Lowest thermal resistance design
◪ High efficiency output
◪ High optical intensity design
◪ Narrow & single peak wavelength design
◪ Pure color output
| UV-A | LN-CVS35UV-P120 |
| POWER | 192-300W |
| Dominant Wavelength | 365nm | 385nm | 395nm |
| Optical Power | 95000-110000mW | 120000-140000mW | 125000-150000mW |
| IF | 6000-8400mA
(Test=8400mA) |
| VF | 34-38V |
| WHOLE SIZE | 35*35MM |
| Lighting Area | 22*35MM |
| VIEW ANGLE | 120° |
| LENS | QUARTZ GLASS LENS |
| SUBSTRATE | ALN Coppering |
| CHIPS | VERTICAL EPISTAR
(LG or HPO) |
Note:
A.PRICE IS WITHOUT VAT, AND KPCS=1000PCS.
B.EX-WORK QUOTE BASE,SHIPPING COST IS NOT INCLUDED.
C.WARRANTY IS 2 YRS.
D.PREPAID IS REQUIRED ONCE ORDER CONFIRMED,TT BALANCE ONCE READY TO SHIPPING.
E.PRODUCTION CYCLE IS 7-10 WORK DAYS.
F.OEM & ODM IS ACCEPTABLE.
Company Features1. The application of high technology is good for the production of uv led chip .
2. Shenzhen Learnew Optoelectronics Technology Co., Ltd. uses the utmost care to create products that satisfy our customers. Inquire now!
