Enterprise Strength
-
Learnew Optoelectronics Technology firmly believes in the concept of 'customer first, reputation first' and treats each customer sincerely. We strive to meet their requirements and solve their doubts.
Company Advantages1. Our Learnew
uv led chip is available in various specifications and is designed and manufactured as per the requirements of our customers.
2. uv led chip would work in a safe and serviceable fashion.
3. HENZHEN LEARNEW OPTOELECTRONICS TECHNOLOGY CO LIMITED. has a higher product development capacity.
4. HENZHEN LEARNEW OPTOELECTRONICS TECHNOLOGY CO LIMITED. puts customer satisfaction at the first place.
UV LED Array series
UV LED R&D,Manufacture is one of important business structure in Learnew.Since 2013,Learnew first time present “Inorganic encapsulation” in high power UVA package,Core technical is we manage the most efficiency output and thermal resistance design.Even in 300-600W,Learnew UV series give best performance in lifetime and continual stable output.
Learnew UV(UVA & UVC) 1-600W series for different UV application,such as offset printer,exposure application,large-scale inkjet printer,3D printer,Printing & Curing application,Sterillization etc.Learnew standard design UVA(360-410nm) & UVC(260-280nm) for your pleasure need.
Product feature
◪ Inorganic encapsulation
◪ Lowest thermal resistance design
◪ High efficiency output
◪ High optical intensity design
◪ Narrow & single peak wavelength design
◪ Pure color output
| UV-A | LN-SMD6868UV-P4 |
| POWER | 5-10W |
| Dominant Wavelength | 365nm | 385nm | 395nm |
| Optical Power | 3200-4000mW | 4000-4500mW | 4100-5000mW |
| IF | 500-700mA
(Test=700mA) |
| VF | 12-15V |
| WHOLE SIZE | 6.8*6.8MM |
| Lighting Area | R5.0MM |
| VIEW ANGLE | 60° |
| LENS | QUARTZ GLASS LENS |
| SUBSTRATE | ALN Coppering |
| CHIPS | VERTICAL EPISTAR
(LG or HPO) |
Note:
A.PRICE IS WITHOUT VAT, AND KPCS=1000PCS.
B.EX-WORK QUOTE BASE,SHIPPING COST IS NOT INCLUDED.
C.WARRANTY IS 2 YRS.
D.PREPAID IS REQUIRED ONCE ORDER CONFIRMED,TT BALANCE ONCE READY TO SHIPPING.
E.PRODUCTION CYCLE IS 7-10 WORK DAYS.
F.OEM & ODM IS ACCEPTABLE.
Company Features1. HENZHEN LEARNEW OPTOELECTRONICS TECHNOLOGY CO LIMITED. has been dedicated to manufacturing superior uv led chip .
2. HENZHEN LEARNEW OPTOELECTRONICS TECHNOLOGY CO LIMITED. builds up a first-class rgb uv led professional R&D team with numbers of technical personnel.
3. HENZHEN LEARNEW OPTOELECTRONICS TECHNOLOGY CO LIMITED. is dedicated to be the top notch professional led cob 200w company. Ask online! HENZHEN LEARNEW OPTOELECTRONICS TECHNOLOGY CO LIMITED. promotes green, low-carbon environmental protection concepts. Ask online!
